£4,992.00 (£4,160.00 ex VAT) – £5,100.00 (£4,250.00 ex VAT)
With tons of channels, a wide palette of digital connectivity, built-in SPQ processing, Eucon control compatibility, internal summing engine and drivers for macOS and Windows 10, it is a pristine digital audio interface by any measure and is suited for just about any application.
Up to 8 analogue cards can be installed, providing 64 analogue input or output audio channels with the renowned DAD high-end sonic quality.
The Thunder Core-driven AX64 is a powerful and versatile
modular multi-format audio interface with 8 slots for the Pristine
audio I/O cards known from the AX32 and Penta product family.
Up to 8 analogue cards can be installed providing 64 analogue
input or output audio channels with well know DAD high-end
sonic quality. With tons of channels, a wide palette of digital
connectivity, built-in SPQ processing, Eucon control compatibility,
internal summing engine and drivers for macOS and Windows 10,
it is a pristine digital audio interface by any measure and for just
about any application.
AX64 is the ultimate modular multi-format interface. That said,
AX64 is of course ready to take on a wealth of other tasks in the
post production, studio, live music and installed audio spheres.
With Dante, MADI and ADAT ports onboard and native interfaces
and versatile, flexible DADman routing control available, it is a
stellar AD/D, D/A and D/D converter that can grab any digital
audio channel – convert it if needed – and route it anywhere.
The DAD Thunder Core Technology provides a Thunderbolt 3
connection with near-zero latency for interfacing between
audio applications on MacOS or Windows computers and the
Thunder Core audio hardware. The interface provides a fast
Thunderbolt 3 connection and a data transfer with 2 samples
latency on the connection and a total of 9 samples in the digital
interface as a total including EQ and summing processing in
the unit.
The channel capacity is up – to 256 audio channels
@ 48 and 96 kHz, and the latency @ 96 kHz is 95 micro seconds.
The total round trip latency with an audio software application will
depend on the bu er size set for the application. With a bu er size
of 32 samples the latency is 670 micro seconds at 96 kHz.
The AX64 Multi-format Audio A/D and D/A converter, router and
monitoring interface provides 256 channels of Thunderbolt 3,
Dante and MADI as well as ADAT.
Another application would be as a dedicated audio interface for
your DAW. Whether you run Pro Tools, Logic Pro, Nuendo, Cubase,
Ableton Live, Digital Performer or any other DAW, AX64 can be
your super low-latency entrance. With the ADAT, MADI and Dante
connectivity, or any combination of DAD card options AX64 can
be the audio center pieces of your studio.
AX64 can be installed with up to 8 optional I/O cards. These are
the cards available for DAD AX64 and other Penta products. The cards are fully inter-changeable between the products:
To discuss your projects needs, or to book a demo, don’t hesitate to contact us!
To get in touch, call us on 0118 402 5090
